What is A Surge Arrester, and How Does it Work?
A surge arrester is a protective device that safeguards electrical systems from high-voltage shocks, surges, and other power-related irregularities. It works by absorbing the energy from a voltage spike or other abnormally high potential before it reaches the system's components. In essence, it acts as a barrier against high-voltage spikes, protecting the materials and objects connected to the circuit.
It is typically used in electric circuits that could be adversely affected by extraordinary differences in voltage or electric current during powering up, because these often result in fires, electrical damages to electronics or even disrupt service. The surge arrester stores small amounts of electricity rather than diverting it, protecting electronics and preventing disruptions.
In this blog post, we will explain the different types of surge arresters, how they work, and why they are essential for protecting electrical power systems.
How Surge Arresters Work
Surge arresters work by intercepting any transient overvoltage that enters a system or circuit. When such a voltage spike occurs, the arrester routes it away from sensitive equipment through the ground connection until it dissipates safely. This happens very quickly – often within microseconds – ensuring that no harm is done to people or sensitive electronics & property.
The most common type of surge arrester consists of two main components: a spark gap and a series of metal oxide varistors (MOVs). The spark gap provides a low-resistance path for the unwanted current to flow. When triggered, it conducts electricity between its two electrodes to divert excessive voltage away from the protected system or circuit.
MOVs provide additional protection against surges that exceed the spark gap's capabilities. They are composed of several layers of zinc oxide particles that act as resistors when exposed to high voltages, absorbing excess energy before it reaches sensitive equipment.
Surge Arresters for Home
Surge Arresters for Home are an essential tool for any residential home or apartment. Surge protection is necessary because it guards against potentially damaging power surges, which can lead to severe damage to your appliances, electronics, wires and outlets in your home. Surge arresters for the home come in a range of sizes, making it easy to find the one that best suits your needs. Not only do surge arresters protect your electronics and wiring from high voltage spikes, but they also give you peace of mind, knowing that you are guarded against all of life's little electrical surprises.
Why Surge Arresters Are Necessary
Surge arresters are essential for protecting electrical systems from damage due to lightning strikes, power surges, and transient overvoltages. Without them, expensive repairs could be needed regularly - not only because of the cost associated with replacing damaged components but also due to downtime caused by having an impaired system out of service while repairs take place.
Furthermore, without surge protection in place, there’s always the risk of injury or death from faulty wiring or malfunctioning equipment if left unchecked after an electrical surge event. Therefore, installing surge arresters is highly recommended wherever possible to reduce both financial costs and safety risks associated with power system surges.
High Voltage Surge Arrester
A high-voltage surge arrester can be an invaluable tool for anyone who owns appliances and electronics. High-voltage surges can cause severe damage, so investing in a high-voltage surge arrester is a smart way to protect your devices from potentially catastrophic problems.
High-voltage surge arresters provide superior protection by immediately absorbing excess voltage caused by surges, preventing it from reaching sensitive electronic components. Additionally, they are designed to automatically reset after a few seconds when the threat has been eliminated. High-voltage surge arresters offer peace of mind, knowing that our most cherished electronic investments are safe and secure.
15 KV Surge Arrester
15 KV Surge Arresters are an essential component for modern power infrastructure, reducing the risk of safety hazards and equipment failures from overvoltage transients. 15 KV Surge Arresters optimise protection in medium-voltage systems by using patented arrestor technology to quickly reduce voltage surges to a safe level before they can cause any harm. They are designed not only to limit electrical damage, but also to prevent downtime of critical equipment in order to keep energy running smoothly and efficiently. 15 KV Surge Arresters provide peace of mind that your medium-voltage system is properly protected against unexpected power disruptions.
Ohio Brass Surge Protectors
Ohio Brass Surge Protectors are a must-have for any home or business with sensitive electronics. Ohio Brass Surge Protectors offer reliable protection from power surges and power outages. Ohio Brass has developed surge protectors with advanced technology that can provide up to 8,000 Joules of energy suppression. This phenomenal level of protection helps safeguard valuable electronics and keeps users safe from electrical hazards.
Ohio Brass has also integrated a 15-minute thermal cut-off fuse into the surge protectors, so if the device is subject to an abnormally high voltage, it will be shut off quickly, protecting their electronics and cutting losses dramatically. Ohio Brass' advanced surge protection makes their surge protectors the ideal choice for all your power needs.
Advantages of Using Surge Arresters
Protection from Lightning
Surge arresters provide a powerful layer of protection against one of nature's most destructive forces—lightning. By combining physical encasement with electrical grounding, surge arresters can direct destructive surges away from equipment and wiring systems.
They act like lightning rods, protecting homes and businesses from damage caused by lightning strikes or other power surges. With surge arresters, individuals and companies alike can take comfort in knowing their equipment is protected from sudden surges and potential overvoltage damage.
Furthermore, these protective devices can be easily installed in existing wiring systems without incurring high costs or labor. Investing in some basic surge arrester protection can save time and money due to the mitigation of future damages. Now that's just thoughtful planning!
Surge arresters can be an invaluable tool for protecting sensitive devices and electronics from power surges. Unlike uninterruptible power supplies, which serve as a buffer between the power source and the device, surge arresters completely bypass the affected device with a specialized circuit, preventing dangerous electrical spikes from entering it.
This type of protection keeps hardware free from damage, saving time, money, and frustration. In addition to protecting equipment from power surges, surge arresters also protect phone lines and other communication systems from lightning strikes. This allows essential information to remain secure while ensuring efficient operations in thunderstorm-prone areas.
Overall, using surge arresters offers reliable protection against damaging power surges that can cause significant financial losses by destroying valuable hardware.
Reduced Maintenance Costs
The installation of surge arresters can be a great asset to any power system. Not only do they help protect vital equipment from voltage surges, but they also reduce maintenance costs as well. By diverting excess energy away from your infrastructure, surge arresters can prevent components from constantly working beyond their usual levels and from premature wear.
This means mechanical and electrical systems will require less upkeep and repair, helping save money in the long run. In addition, surge arresters are durable enough to withstand multiple storms and other surges, making them a wise investment for anyone with an electricity-driven environment.
Electronic Equipment Safety
Surge arresters are essential safety devices that protect electrical equipment from voltage spikes and surges. The advantages of using surge arresters are numerous and include improved safety, increased system life expectancy, prevention of costly repairs, and reduced maintenance costs.
Surge arresters provide essential protection by monitoring incoming electrical currents and helping prevent sudden changes that could damage or even fail the protected system.
Additionally, they can help to ensure that your valued electronics remain cheaper to repair and run for longer. By protecting your electronic systems from external power infractions, surge arresters provide greatly improved safety in both home and workplace settings.
Cleaner Power
Surge arresters are lifesavers in a world where electricity is essential for daily use. They protect valuable electrical equipment, prevent damage from electrical overloads, and address longer-term power quality issues. Not only that, but they also help to provide cleaner power to consumers.
Surge arresters divert electrical disturbances away from sensitive equipment, ensuring higher-quality energy use. This helps reduce the risk of unwanted outages or costly repairs while making sure the energy delivered is safer and more reliable.
Additionally, surge arresters can significantly reduce the accumulation of soot and other hazardous pollutants generated by the burning of coal or diesel, a common source of power generation worldwide, including in developing countries. In this way, investing in surge arresters brings numerous benefits – cleaner power, increased safety levels, and improved durability – making it an investment worth considering.
Surge Arrester Types
Surge arresters are safety devices that protect electrical systems and appliances from damage caused by power surges. Surge arresters vary by application, with each offering different levels of protection. Well-known types include gas discharge tubes (GDTs), which have a high energy absorption capacity, and thyristors, which use controlled energy flow to absorb overvoltages and prevent them from entering the system.
Sector arresters provide an automatic design that detects large overcurrents instantaneously and acts to prevent damage, while voltage-limiting designs reduce the intensity of surge voltages before they reach sensitive components. Surge protection professionals regularly compare surge arrester types for their respective applications, as selecting the wrong kind can result in inadequate protection or inefficient operation.
What Are The Different Surge Arrester Types?
Station Class
Station Class surge arresters are specifically designed to protect high-voltage power systems from voltage spikes. These are large and rugged arresters that typically prevent damage to turbines, high-voltage transformers, and other high-energy electrical equipment in power distribution systems.
Station Class surge arresters boast a particularly long service life since they are designed with reliable construction, which is well-equipped for the rigors of extreme environmental conditions. When properly maintained, these surge arresters provide reliable protection against voltage transients and eliminate the need for costly repairs due to lightning strikes.
Distribution Class
Distribution-class surge arresters are essential for protecting valuable electrical equipment from the damaging effects of lightning. When installed within a facility, this type of arrester protects medium-voltage equipment by absorbing and diverting excess electrical charges to ground.
It achieves this through its semiconductor device that’s designed to short-circuit in order to provide an alternate path for any overvoltage conditions. This provides a more permanent solution than manually resetting circuits, where applicable.
For electrical facilities seeking comprehensive protection, distribution-class surge arresters can provide peace of mind now and in the future.
Residential Class
Residential surge arresters provide paramount safety to homeowners while also remaining cost-effective. These products work to protect home electronic components from surges in electricity and other unexpected spikes that result from lightning, utility switching, or accidental contact.
With the added security of these residential surge arresters, homeowners can rest easy knowing their critical systems are protected against potentially permanent damage or destruction from lightning strikes.
Not only do residential class surge arresters offer reliable protection, but they also offer flexibility -interior and exterior models are available for different environments and are easy to install. Wherever there is an increased risk of electrical surges, these resilient residential-class surge arresters can be a reliable line of defense.
Portable Class
Portable Class surge arresters are an invaluable tool for protecting people and devices from electrical surges. These devices are relatively lightweight and can be quickly deployed in a variety of applications. Unlike stationary class arresters, portable class arresters are easily transportable and can be used in numerous applications, from residential panel boards to switchgear systems. Their easy installation ensures a correct and secure setup, and they can be tested before being placed into service.
Furthermore, it's highly customizable, with various design settings available given the device’s intended purpose. In terms of safety, these temperature-compensated damping structures feature arc-extinguishing chambers that enable them to respond immediately to high-grade surges. Its many features enhance its overall efficiency, making it an incredibly reliable device for any necessary application.
Lightning Class
Lightning-class surge arresters are essential components of electrical systems and provide top-tier protection against lightning strikes, electrical surges, and other costly damages. Using specific types of surge arresters can be a very cost-effective way to protect any electrical system.
These devices absorb high voltages and currents, redirecting them away from sensitive equipment. With the use of these protective devices, costly repairs or replacements become unnecessary. Lightning-class surge arresters are undoubtedly an excellent solution for protecting vital equipment from lightning and electrical malfunctions.
Solar Class
Solar Class surge arresters are the go-to choice for solar energy systems due to their reliability and dependability. These surge arresters provide safe, consistent protection by utilizing a unique class of energy storage materials that allow fast discharge during short-duration surges while also providing high withstand current.
Furthermore, Solar Class arresters come equipped with lightning or surge detectors which provide added protection and alert users to any potential high voltage surges that may be occurring. This type of arrester is designed to be both long-lasting and durable, ensuring solar energy systems are protected no matter the climate or weather.
Ultimately, investing in a Solar Class arrester is an effective way to protect a solar power system from dangerous voltage fluctuations.
What exactly is a surge arrester?
A surge arrester is a protective device installed in an electrical system that guards against abnormally high voltage spikes or transient surges. When a sudden overāvoltage occurs (from lightning, switching surges, etc.), the arrester provides a safe path for the excess energy — redirecting it to ground — to protect wiring, appliances, or other equipment.
Eaton
+2
How does a surge arrester work ā under normal conditions and during a surge?
Under normal voltage conditions: the arrester remains inactive and does not affect the system or normal electrical flow.
Eshop
+1
During a voltage spike or surge: the device “activates” — often via components such as a spark gap or a varistor (such as a Metal Oxide Varistor, MOV) — and creates a lowāresistance route to ground so the excess energy bypasses sensitive equipment.
ACDC Electric
+2
,
As soon as the over-voltage passes, the surge arrester returns to its resting (non-conductive) state, ready for the next event.
Eshop
+1
Why is a surge arrester necessary ā what risks does it protect against?
Surge arresters help protect homes, businesses, and electrical devices from:
Power surges or spikes caused by switching operations, utility fluctuations, or other anomalies.
ETEI
+2
Chint Global
+2
Indirect effects of lightning or nearby lightningāinduced surges (though not necessarily a direct lightning strike).
Chint Global
+1
Damage to wiring, appliances, electronics, risk of fire, system failures, or costly repairs that can result from overvoltage events.
ACDC Electric
+2
ETEI
+2
Where/how is a surge arrester typically used or installed?
Surge arresters can be used in homes, apartments, or any building’s electrical distribution system.
ACDC Electric
+2
They are often installed at or near the service entrance, main panel, or before sensitive equipment so any surge is intercepted before reaching downstream wiring or devices.
ETEI
+1
For larger installations or powerādistribution systems (e.g. mediumāvoltage systems), there are specially rated “station class” or “distribution class” surge arresters.
ACDC Electric
+1
What types or āclassesā of surge arresters exist?
Residentialāclass: for typical home/apartment wiring and household electronics.
Distributionāclass / Stationāclass: for more demanding systems — industrial, mediumāvoltage, or utilityāscale distribution.
There are also design variations based on the internal protection mechanism (e.g. MOVābased, sparkāgap, gasādischarge tube, etc.), chosen depending on the expected surge type and energy level.
ACDC Electric
+2
ETEI
+2
Does a surge arrester guarantee protection against direct lightning strikes?
No — while surge arresters help significantly against voltage spikes and transients (often from nearby lightning or grid switching), they are generally not designed to survive a direct lightning strike. Their purpose is to handle transient overvoltage, not the full power/energy of a strike.
Chint Global
+1
Will installing a surge arrester affect normal electricity flow or performance?
No — under normal operating voltages, a surge arrester remains inactive and does not interfere with or degrade normal electrical flow or device operation.
Eshop
+1
Are surge arrester and surge protector the same thing?
They are related but not always the same. The term “surge arrester” often refers to devices for protecting larger electrical systems or wiring infrastructure, especially at the service entrance or distribution level. “Surge protector” (or surge suppressor) usually refers to devices (like powerāstrip protectors) used for individual electronics or appliances. The internal working principle may overlap (MOVs, clamping), but their scope and application differ.
ACDC Electric
+2
Wikipedia
+2
What are the benefits of installing a surge arrester?
Protects sensitive appliances and electronics from damage due to surges or spikes.
Helps prevent electrical fires or wiring damage from overāvoltage events.
Reduces longāterm maintenance and repair costs for electrical systems by preventing surgeārelated damage.
Offers peace of mind: once installed correctly and grounded, the arrester works automatically and transparently — no daily interaction needed.
ACDC Electric
+1
APC Surge Arrest Surge Protector
APC Surge Arrest Surge Protector is a must-have for any home or business. It provides Safety Protection, Surge Suppression, and Data Line Protection to safeguard valuable electronics, including computers, printers, gaming consoles, and more.
The APC Surge Arrest helps prevent damage from surges and spikes caused by external factors such as lightning strikes or power outages. Unlike other surge protector devices on the market, APC’s is certified and guaranteed to protect your equipment against catastrophic failure caused by electrical surges or spikes.
APC Surge Arrest also features a diagnostic LED that indicates surge protection is working correctly, giving you peace of mind that your equipment is safe from damaging power outages. With APC Surge Arrest, you can rest assured that your electronic equipment investments are protected from sudden power disturbances.
Surge Arrester vs. Surge Protector
Surge arresters and surge protectors are two critical electrical components used to protect valuable electronics from power surges. Surge arresters are designed to divert sudden excess energy or voltage, known as a surge, away from vulnerable machinery or appliances. In contrast, surge protectors divert the surge to ground.
Surge protectors also provide additional protection by filtering out electromagnetic noise before it reaches equipment. Surge arresters are primarily used for large-scale operations fed by transformers, such as factories and businesses. In contrast, surge protectors are commonly found at home in the form of specialty power strips and plug-in devices.
Surge arresters and surge protectors may look alike on the outside, but they fulfil vastly different functions when it comes to shielding sensitive electronics.
Surge Arrester vs. Lightning Arrester
Surge Arrester Basics
A surge arrester is designed to protect electrical equipment from voltage spikes caused by lightning strikes, power line faults, or other unexpected events. This type of arrester works by diverting excess current away from sensitive equipment.
When the voltage exceeds a certain threshold, the arrester will conduct electricity to ground to prevent damage to other components in the system. A surge arrester usually has two terminals—the input terminal and the output terminal—and operates on a simple principle of redirecting electricity when it reaches a certain level.
Lightning Arresters Basics
Unlike surge arresters, lightning arresters are specifically designed to protect against direct lightning strikes. This type of protection device works by grounding potential surges before they reach sensitive components in the system.
Lightning arresters also have two terminals—the input terminal and ground terminal—but they operate on a different principle than surge arresters. Instead of conducting electricity when it reaches a certain level, lightning arresters act as insulators until they detect an excessive amount of current flowing through them. At this point, they connect the system to ground to protect other components in the system.
Difference Between Surge Arresters & Lightning Arresters
Surge Arresters and Lightning Arresters serve an essential purpose when it comes to avoiding costly damages caused by lightning and power surges. Although the two are similar in that they both help protect equipment against possible electrical discharges, they have some noteworthy differences.
One of the bigger distinctions is that surge arresters work on low-voltage lines, while lightning arresters are needed to service much higher-voltage lines. As far as construction goes, most surge arresters feature multiple layers of insulator material, allowing them to be placed a larger distance away from buildings and other structures without sacrificing performance. While both devices provide valuable protection for industrial sites, doing your research about which one best service your needs is key to having a happy, safe outcome!
Having a Surge Arrester Installed
Surge arresters are vitally important for protecting electrical systems from damage due to transient overvoltages such as lightning strikes or power outages. They work by intercepting these voltage spikes and diverting them away from sensitive equipment before they can cause any harm.
Most surge arresters consist of two main components - a spark gap and metal oxide varistors - which work together quickly enough that no damage is done when such events occur. Installing surge arresters is highly recommended for any power system in order to reduce costs associated with repairs as well as safety risks posed by malfunctioning equipment that has been subjected to an electrical surge event without proper protection in place.
Affordable Electrical Services
Dealing with an electrical surge problem at home can be incredibly distressing, and many electricians and companies are willing to exploit people experiencing such issues by charging them high fees. At AC-DC Electric, we strive to provide high-quality electrical services at affordable rates.
Our nearby electricians can also offer you a free estimate before you hire them. This ensures you remain aware of how much you will need to pay before using our services.
If you’re ready to tackle your residential property’s electrical problems quickly,
please get in touch with AC-DC Electric today. Our experts are always happy and ready to help residents in
Fort Collins,
Loveland,
Eaton, Evans, Johnstown & Windsor. Call today for a free estimate at 970-330-1656.
